Sanctum Gateway runbook

Sanctum Gateway runbook — an operator's workbench laid out like a clockmaker's table: a brass key-rotation rig, a magnifier hovering over a debug receipt, a coil of backup tape, and a tiny cartoon of a door that refuses to close.

It’s 2 a.m. The tunnel is up, DNS resolves, and bridge.nepveu.name answers every request with the same flat 401. Nothing is on fire — something is just quietly wrong, which is worse. Tommy the Abyssinian would tell you the door that won’t close is a human problem, and he stopped having those the morning he became a force-ghost. You don’t have that luxury tonight.

The Sanctum Gateway spec covers architecture, threat model, and every resolved decision, and it is the right thing to read on a calm afternoon when you want to understand how the whole thing fits together and why each piece is shaped the way it is. This page is the other half. It is the runbook a future you reaches for when the spec has stopped being useful and the fix has to come from hands on keys. No theory. Just steps.

Bring-up on a fresh Mac

A Mac died, or you bought a new one, and the gateway has to live on it by morning. Assumes brew, uv, sops, age, cloudflared, gh, jq, shasum (any CLT install) are present. If they aren’t, that’s the detour you take first.

# 1. Repo + Python env
sudo mkdir -p /opt/sanctum/bridge /opt/sanctum/keys /var/log/sanctum
sudo chown -R $(whoami) /opt/sanctum /var/log/sanctum
sudo chmod 700 /opt/sanctum/keys
git clone [email protected]:Ogilthorp3/sanctum-gateway.git /opt/sanctum/bridge
cd /opt/sanctum/bridge
uv python pin 3.12
uv sync --extra dev
make test                                # 47/47 must be green

# 2. Restore the age master key
op item get "SanctumBridge — age private key (master)" \
  --reveal --format json \
  | jq -r '.fields[] | select(.label=="private_key") | .value' \
  > /opt/sanctum/keys/age.key
chmod 600 /opt/sanctum/keys/age.key

# 3. Verify decryption round-trips
SOPS_AGE_KEY_FILE=/opt/sanctum/keys/age.key sops -d secrets.yaml | head -3

# 4. Install launchd jobs
sudo install -m 644 -o root -g wheel \
    launchd/name.nepveu.sanctum-bridge.plist /Library/LaunchDaemons/
sudo launchctl load -w /Library/LaunchDaemons/name.nepveu.sanctum-bridge.plist
cp launchd/sanctum-bridge-rotate ~/.sanctum/bin/
cp launchd/sanctum-bridge-canary ~/.sanctum/bin/
cp launchd/com.sanctum.bridge-rotate.plist ~/Library/LaunchAgents/
cp launchd/com.sanctum.bridge-canary.plist ~/Library/LaunchAgents/
cp launchd/com.sanctum.bridge-manifest-sync.plist ~/Library/LaunchAgents/
launchctl load ~/Library/LaunchAgents/com.sanctum.bridge-rotate.plist
launchctl load ~/Library/LaunchAgents/com.sanctum.bridge-canary.plist
launchctl load ~/Library/LaunchAgents/com.sanctum.bridge-manifest-sync.plist

# 5. Newsyslog rotation
sudo install -m 644 -o root -g wheel \
    etc/newsyslog.d/sanctum-bridge.conf /etc/newsyslog.d/

# 6. Smoke check
sanctum bridge doctor                    # all rows green
sanctum bridge upload README.md "01_Fund Admin/_smoke" --doc-type meeting-notes

The Cloudflare side — Tunnel hostname, Access app + service token policy, DNS CNAME — is account state, not host state. Bringing up a new Mac re-uses the existing tunnel and Access app, so you don’t touch any of it. Re-creating those is a separate procedure, and rarely needed; nothing about the tunnel is host-bound.

`sanctum bridge doctor` — what each row means

This is the first thing you run and the last thing you trust. Each row is a small yes-or-no; read them top to bottom.

keychain: sanctum-bridge-cf-access-client-id     OK/FAIL
keychain: sanctum-bridge-cf-access-client-secret OK/FAIL
keychain: sanctum-bridge-cf-access-token-id      OK/FAIL
keychain: sanctum-bridge-hmac-sharepoint         OK/FAIL
keychain: sanctum-bridge-sp-*                    OK or SKIP (gateway-only)
bridge /_health                                   reachable + version + commit
modules loaded                                    list — sharepoint, optionally slack
uptime                                            since last respawn
allowlist count                                   count of allowed_roots from the SoT
CF Access JWT                                     "enabled" — secrets.cloudflare.* set
rotator last_run                                  hours since last run; FAIL if >48 h
rotator outcome                                   skip / rotated / fail
requests since boot                               sanity check

FAIL on Keychain → a previous bring-up didn’t complete; re-run the appropriate security add-generic-password line from secrets.yaml.

FAIL on bridge /_health → daemon wedged or tunnel down. See Recovering a wedged daemon and Tunnel debugging.

FAIL on rotator → either the script crashed or the launchd timer isn’t loaded. tail ~/.openclaw/logs/sanctum-bridge-rotate.log for the last run’s stderr.

Secret rotation

Three secrets, three different rotation stories — and only one of them rotates itself while you sleep. The secret rotation playbook covers the wider trifecta; here is what the gateway needs specifically.

CF Access service token

Automatic via com.sanctum.bridge-rotate, daily 09:00 local. Gates on the current token’s expires_at; fires when ≤ 7 days remain. Two-token cutover policy means a verify failure during rotation rolls back to old-only, with the bridge still serving on the old token. A successful rotation updates Keychain + 1Password in place and deletes the old token.

To force-run early (e.g. you suspect the secret leaked):

ROTATE_WITHIN_DAYS=999 ~/.sanctum/bin/sanctum-bridge-rotate

To rotate manually via the dashboard, follow the runbook at the bottom of sanctum-bridge-rotate itself — the script is the canonical sequence.

HMAC secret (per module)

Rotation is manual today: edit secrets.yaml via SOPS, restart the bridge, push the new secret to every consuming skill’s runtime env or Keychain. There’s no token-list-style cutover; coordinate with skills beforehand.

Azure SharePoint app secret

Update via the Azure portal, then:

SOPS_AGE_KEY_FILE=/opt/sanctum/keys/age.key \
  sops set /opt/sanctum/bridge/secrets.yaml \
    '["sharepoint"]["client_secret"]' '"<new value>"'
security add-generic-password -s sanctum-bridge-sp-client-secret \
    -a client_secret -w '<new value>' -U
op item edit 74gcslibchm5ru5nsf352tdu3a \
    "credential[concealed]=<new value>"
sudo launchctl kickstart -k system/name.nepveu.sanctum-bridge

Age master key

Don’t. The encrypted secrets.yaml is bound to this key — losing it forces a from-scratch bootstrap. The 1Password Secure Note named SanctumBridge — age private key (master) is the recovery copy, and it is the only thing standing between you and that bootstrap.

Recovering a wedged daemon

The daemon wedged. doctor is red on bridge /_health, and you have about ninety seconds of patience before you start inventing theories. Don’t invent yet — bounce it first.

# 1. Confirm it's down
sanctum bridge doctor                # red on bridge /_health
pgrep -fl '\\-m sanctum_bridge'
sudo launchctl list | grep sanctum-bridge   # PID column should be a number

# 2. Tail the most recent boot
tail -50 /var/log/sanctum/bridge.err.log

# 3. Bounce
sudo launchctl kickstart -k system/name.nepveu.sanctum-bridge
sleep 5
sanctum bridge doctor

If the daemon’s log shows a SOPS decrypt failure, the age key got moved or its mode changed. chmod 600 /opt/sanctum/keys/age.key and bounce.

If the daemon refuses to bootstrap (launchctl bootstrap returns EIO), fall back to sudo launchctl load -w /Library/LaunchDaemons/name.nepveu.sanctum-bridge.plist — the legacy load path works around a launchd domain transition issue.

Tunnel debugging

If the bounce didn’t fix it, the trouble is somewhere between you and the daemon, not in the daemon itself. Walk the path from the outside in.

# 1. Is cloudflared running?
launchctl list | grep -i cloud
ps aux | grep cloudflared | grep -v grep

# 2. Does DNS still point at CF Anycast?
dig +short bridge.nepveu.name @1.1.1.1   # 172.64.x.x or 104.x.x.x

# 3. Does CF Access front the hostname?
curl -sS -o /dev/null -w 'HTTP %{http_code}\n' https://bridge.nepveu.name/_health
# expect 403 without service-token headers

# 4. Hit local /_health directly
curl -sS http://127.0.0.1:8443/_health

A 502 with valid headers means the bridge daemon is down (see above). A 403 without cf_access_failed is a CF Access policy issue — probably the token expired and the rotator hasn’t fired. A cf_access_failed jwt_invalid on the local path means cloudflare.access_aud in secrets.yaml doesn’t match the real CF Access app’s AUD; re-fetch via /accounts/{acc}/access/apps/{id} and re-encrypt. That last one is the 2 a.m. 401 from the top of the page.

Restoring from backup

The Mac is gone entirely — this is the from-nothing path. The backup and restore page is the general drill; the gateway’s own order matters because the age key must never come back the way everything else does. The restic snapshot at /Volumes/T9/sanctum-restic (or the gdrive remote) carries /opt/sanctum, ~/Projects/work-skills, and the launchd/ plist sources.

# 1. Restic restore the bridge tree
restic -r /Volumes/T9/sanctum-restic restore latest \
  --target / --include /opt/sanctum

# 2. Restore the age key from 1Password (NOT from restic; safer)
op item get "SanctumBridge — age private key (master)" \
  --reveal --format json \
  | jq -r '.fields[] | select(.label=="private_key") | .value' \
  > /opt/sanctum/keys/age.key
chmod 600 /opt/sanctum/keys/age.key

# 3. Restic the launchd-sources directory
restic -r /Volumes/T9/sanctum-restic restore latest \
  --target / --include /Users/neo/Projects/work-skills

# 4. Re-install plists + start
# (same step 4-5 from the bring-up section)

Verify with sanctum bridge doctor. If every row is green, you’re back.

When in doubt

When the runbook runs out, the architecture spec tells you what and why — this page told you how. Between the two sits /var/log/sanctum/audit.jsonl, the one file that remembers what actually happened, in order, without an opinion. Read it before you trust your memory of the night.

Then go back to bed. Tommy filed his dawn report the moment the sun cleared the ridge, without being asked, the way he has every morning for fifteen years and every morning since — and the gateway, wedged or not, will still be there when you wake up. It always is.
