Memory Vault

We built something that dreams.

Every morning at 4:17, while the haus sleeps, the vault does what a brain does overnight: it sorts the day’s raw observations, keeps what matters, and forgets the rest on purpose. Forgetting, here, is not a bug we tolerate — it is the feature we designed for. Somewhere during development we realized we’d shipped a system that remembers where you left your SSH keys, forgets trivial session data, and dreams at 4 AM. The horror movie writes itself.

The Memory Vault is Sanctum’s shared knowledge base, modeled on how human memory actually works. Three tiers of temporal memory — working, short-term, long-term — sit on top of a four-system backend stack, and a daily consolidation pass acts like sleep, distilling raw observations into lasting knowledge.

Note

This page is reconciled against the live vault by hand — last pass 2026-06-09, after the doc and the code had quietly drifted apart. The vault remembers things automatically; its documentation, it turns out, does not.

Memory Stack

Today’s stack is the local git vault, fronted by two access surfaces (a Rust REST service and a Python MCP server), plus the entity graph running on the VM. The doc once described a four-layer design that included a mem0.ai cloud tier; that integration was never wired up, and the privacy posture decided on 2026-05-16 (vault GitHub mirror archived, “the haus does not sync its thoughts to the cloud”) makes wiring it now an explicit policy violation. Honesty over aspiration.

Layer	Role	Backend	Cost
Memory Vault	Git-native versioned source of truth, primary cross-agent semantic memory	Local-only git repo at ~/.sanctum/memory/ (GitHub mirror archived 2026-05-16 as part of the privacy scrub; the haus does not sync its thoughts to the cloud)	Free
sanctum-memory REST	The read/write data plane over the vault git repo	Rust service on 127.0.0.1:42069, serving /health and /v1/* HTTP routes (search, read, write, recall, ingest, consolidate)	Free
memory_vault MCP	Tool surface — how an agent’s tool-call becomes a vault operation	Python server (python -m memory_vault) over stdio, exposing the 8 memory_* tools below	Free
Neo4j / Graphiti	Entity relationships & graph queries	Reached via SSH tunnel on local port 31416 (graph runs on the VM, not the host)	Free (self-hosted)

Tip

The vault is the source of truth. All cross-agent semantic memory lives in ~/.sanctum/memory/ — a plain git repo. The Rust service on 127.0.0.1:42069 is the data plane; the memory_vault MCP server is the tool surface agents speak through. Two doors into one room. When the vault and the graph disagree, someone has a long night ahead of them. This has happened twice.

Architecture

┌─────────────────────────────────────────────────────┐
│  LAYER 1: WORKING MEMORY (per-session, ephemeral)   │
│  Agent's context window. Dies when session ends.    │
├─────────────────────────────────────────────────────┤
│  LAYER 2: SHORT-TERM MEMORY (inbox/, days-weeks)    │
│  inbox/{agent}/ — raw observations, session notes   │
│  TTL: 7-30 days. Consolidated or discarded daily.   │
├─────────────────────────────────────────────────────┤
│  LAYER 3: LONG-TERM MEMORY (consolidated, permanent)│
│  knowledge/{topic}/ — semantic facts (timeless)     │
│  events/YYYY/MM/    — significant episodes          │
│  procedures/        — how-to, runbooks              │
│  Neo4j/Graphiti     — entity relationship graph     │
└─────────────────────────────────────────────────────┘

Directory Structure

~/.sanctum/memory/
├── inbox/                  # Short-term, per-agent
│   ├── claude-code/
│   ├── gemini-cli/
│   ├── openclaw/
│   └── home-assistant/
├── knowledge/              # Long-term semantic
│   ├── devices/
│   ├── network/
│   ├── systems/
│   ├── people/
│   └── preferences/
├── events/                 # Long-term episodic
│   └── 2026/03/
├── procedures/             # Long-term procedural
│   ├── troubleshooting/
│   ├── maintenance/
│   └── automation/
├── archive/                # Expired, retained 90 days
└── meta/                   # Schema, consolidation logs

Note Format

Every note has standardized YAML frontmatter. Opinions may vary on whether your haus needs a metadata schema for its thoughts. Opinions are wrong.

---
type: semantic | episodic | procedural | observation | session_summary
source_agent: claude-code | gemini-cli | openclaw | user | system
created: 2026-03-20T17:00:00Z
updated: 2026-03-20T17:00:00Z
last_accessed: 2026-03-20T17:00:00Z
access_count: 3
importance: 0.85
consolidation_status: raw | reviewed | consolidated | archived
ttl_days: null  # null = permanent, or integer days
superseded_by: null  # path to newer version
tags: [network, infrastructure]
related_entities: [mac-mini, ubuntu-vm]
---

# Note Title

Content with [[wikilinks]] to related notes...

Importance Scoring

Every note has a computed importance score (0.0 to 1.0) that determines its TTL. The vault is, in essence, deciding what’s worth remembering. A power you’d think we’d reserve for sentient beings, but here we are.

Importance	TTL	Notes
> 0.8	Permanent	Core knowledge, user-stated facts
0.5 - 0.8	90 days	Agent-observed patterns
0.3 - 0.5	30 days	Single observations
< 0.3	7 days	Ephemeral session data

Score formula: source_weight x recency x access_frequency x link_density

Notes accessed 5+ times are protected from expiry regardless of score. If the system keeps coming back to a memory, there’s probably a reason. Even if that reason is paranoia.

Consolidation

The consolidation engine runs daily at 4:17 AM (LaunchAgent: com.sanctum.memory-consolidate). Like sleep for the brain, except it runs on schedule, never hits snooze, and files a report when it’s done.

1. Scan inbox for notes older than 24 hours
2. Deduplicate against existing long-term knowledge
3. Classify and move to the appropriate long-term directory
4. Recompute importance scores for all active notes
5. Expire notes that have exceeded their TTL
6. Enforce caps via bounded archive-eviction (see Hard Caps below)
7. Clean archive — delete archived notes older than 90 days
8. Generate report in meta/consolidation-log.md

Any agent can trigger consolidation manually via the memory_consolidate MCP tool.

Hard Caps

To prevent bloat, each layer has a maximum note count. Without limits, a system that remembers everything eventually remembers nothing useful — a problem familiar to anyone who’s ever hoarded browser tabs.

Layer	Max Notes	Action at Cap
Inbox	300	Bounded archive-eviction, ≤50/run
Knowledge	1000	Bounded archive-eviction, ≤20/run
Events	500	Bounded archive-eviction, ≤100/run
Procedures	200	Bounded archive-eviction, ≤10/run

Eviction sorts candidates by (importance ascending, created ascending) and skips anything with importance > 0.8 — permanent knowledge survives cap pressure. Each run is rate-limited so a layer at 6× cap converges over many nightly cycles rather than collapsing in one massacre. Archived notes are retained for 90 days via ARCHIVE_RETAIN_DAYS before deletion — eviction is reversible during that window.

MCP Tools (8 total)

Tool	Description
memory_search	Full-text search with tag and folder filters
memory_read	Read a note (auto-tracks access)
memory_write	Create/update with schema enforcement
memory_delete	Remove a note
memory_list	List notes by folder, tag, or type
memory_links	Traverse the wikilink graph
memory_consolidate	Trigger consolidation (dry-run by default)
memory_health	Vault health metrics dashboard

On Mem0 (historical aside)

Earlier versions of this doc described a mem0.ai cloud tier as the primary cross-agent memory layer, with a planned set of MEM0_* cloud tools and a “push to Mem0” step in nightly consolidation. None of that integration was ever wired up — there’s no mem0 client in the repo, no API key, and no mem0.ai traffic from the host.

When the privacy posture was decided on 2026-05-16 (vault GitHub mirror archived, “the haus does not sync its thoughts to the cloud”), Mem0-as-cloud-tier became incompatible with explicit policy. The architecture quietly converged on the local-only model documented above; the doc just hadn’t caught up. This section exists so anyone reading old commit messages or older drafts knows what happened: the cloud tier is not coming back absent a deliberate privacy-posture reversal.

Tool Integration

Tool	Vault Access
Gemini CLI	memory_vault MCP over stdio (~/.gemini/settings.json)
Claude Code	Not currently wired — mcpServers is empty; reach the vault via the :42069 REST API or vault.sh until the MCP is added
OpenClaw agents	SSH skill (vault.sh)
Sanctum automations	:42069 REST API (/v1/write, /v1/search) — the old GitHub path died with the 2026-05-16 archive
Obsidian	File system (~/.sanctum/memory/)
Holocron	HausBrainPanel polls /vault/brain from Force Flow (:4077) every 5s; new-note particles fire in real time off an Electron IPC vault-event bridge, not a separate socket

Tip

Opening the memory directory in Obsidian gives you a graph view of your haus’s knowledge. The wikilinks render as connections. It’s beautiful, informative, and a little like reading someone’s diary — except the someone is your haus infrastructure.

Known Gaps

After tonight’s reconciliation pass (2026-05-29), there are no open implementation gaps — the machinery does what this page says it does: short-term inbox + long-term knowledge/events/procedures, nightly consolidation with bounded archive-eviction, 90-day reversibility, the memory_* tool surface, the :42069 data plane.

One thing the caps table doesn’t show: the vault is currently over cap and grinding down. Events sits at roughly 8× its 500-note cap, and the nightly run evicts 100 events per cycle by design (MAX_EVICT_PER_RUN) rather than archiving thousands in one massacre. That’s the bounded-eviction design working, not a steady state — a system converging, not a system at rest.

The procedures layer was empty for months and is now seeded — 5 high-signal runbooks grounded in recent incidents live under procedures/{troubleshooting,maintenance,automation}/. The layer grows organically from there as incidents teach the haus new procedures worth remembering.

The only architectural decision left open is whether to ever re-introduce a cloud-sync tier (see On Mem0 above). That is a privacy-posture decision, not an engineering gap.

Anti-Bloat Rules

• If derivable from code, logs, or sensors — don’t store it
• If the same fact is stated multiple ways — dedup into one
• If never accessed in 30 days and importance < 0.5 — archive
• Raw data goes to time-series DBs, not memory
• Every episodic memory needs context (who, what, when, why)
• Every semantic memory should be self-contained

Caution

These rules exist because the first version of the vault grew to 2,000 notes in a week and became functionally useless. A memory system that remembers everything is just a hard drive with pretensions.

A haus that remembered everything would remember nothing worth keeping. So the vault forgets, on schedule, the way you do — and every morning at 4:17 it still wakes up knowing where the SSH keys are. That is the whole trick. Your own brain has been running it, unpatched, your entire life.
