2026-05-02: Honest Green

The Holocron crystal was grey when we opened the Status page. Watchdog said overall: degraded, root_causes [ha-tunnel, kiwix, memory-vault, signal-proxy]. Four names. Not one of them was genuinely down in the way that matters — they were a survey of every catalog rot pattern at once, lined up for inspection. By noon the crystal was honest-green, and the morning had taught us that catalog hygiene matters as much as the remediation it triggers. The afternoon found a quieter problem.

Four root causes by morning, none of them new

Two of the four were transient drops: memory-vault had been healthy at 19:32 the night before and just stopped binding :42069; kiwix-serve had been quiet since Apr 27. Both came back with one launchctl bootstrap against the existing plist. No code change, no config change. The launchagent’s KeepAlive had decided “don’t bother” at some point and the pre-reboot path is to nudge it.

The other two were stale catalog entries pointing at retired infrastructure:

ha-tunnel is an ssh -L 18092:127.0.0.1:18092 openclaw plist that predates the OrbStack migration. Today’s reality is that Home Assistant runs on the Mac (OrbStack, host network mode, :8123) and the VM reaches it via socat 10.10.10.1:8123. There is no :18092 anywhere for the tunnel to find. The ha-tunnel.log was a 1.3 MB monument to channel 2: open failed: connect failed stretching back weeks — a daemon dutifully knocking on a door we bricked over in April.

signal-proxy has been retired by design since the 2026-04-27 Colima → OrbStack migration (“Signal-cli stack stayed retired (data preserved bind-mounted)”). The probe is a 60-second curl against a VM service that isn’t there. Guaranteed timeout, every cycle.

Both yamls moved to services/.retired/<name>.yaml.retired-2026-05-02. Ogilthorp3/sanctum-config@3451153.

Tip

The retirement pattern is a rename, not a delete. The .retired/ directory keeps the trail when an architecture later comes back; the date stamp survives git mv so you can see when the catalog rotated without spelunking the log.

The Holocron’s missing sectors

force-flow and sanctum-bridge showed Unknown in the Holocron’s Core Sectors row even though both daemons were live (:4077 and :4078, both serving). The cause was as small as it sounds: the Holocron’s CORE_SECTOR_NAMES array expects watchdog services literally named force-flow and sanctum-bridge, and neither yaml existed. The watchdog couldn’t probe what it didn’t know about; the UI honestly reported what the watchdog returned.

Two new manifests in legacy schema (type: port liveness on localhost:<port>, remediation pointing at the existing launchagents) and the next /check brought sectors to 5 of 5 healthy. The crystal inhaled.

Ogilthorp3/sanctum-config@31089af.

The unwanted guest

By afternoon the watchdog said healthy and the crystal was green, but the Memory Pool bar on the Holocron Status page was red — 61 of 50 GB on manoir. sanctum-mlx (45 GB budget, the resident heavyweight) and lmstudio-coder-14b (~12 GB) were both loaded, which the Capacity Doctrine forbids via exclusive_with. Yesterday’s overnight briefing had already named the conflict; the watchdog had tried to swap and been refused by sanctum-admit. The conflict was still live twelve hours later, quietly defying us the whole time.

Releasing coder-14b (sanctum-admit release lmstudio-coder-14b) freed the budget cleanly — lms unload qwen2.5-coder-14b-instruct returned in milliseconds, the pool dropped to 50.5 of 51.2 GB with 696 MB of headroom. Sixty seconds later, coder-14b was back. Released again. Sixty seconds later, back again.

The hand belonged to ~/.sanctum/scripts/lmstudio-guardian.sh. Its config had EXPECTED_MODEL=qwen2.5-coder-14b-instruct and its tick loop’s autoload_grace is sixty seconds. Every release was a sixty-second window of compliance before the guardian noticed “no model loaded” and lms loaded coder-14b right back over the doctrine. The watchdog and the guardian were both doing what they were told. They were just told different things.

Caution

The guardian doesn’t honour exclusive_with. That’s not a bug — it’s a scope mismatch. The guardian is an LM Studio keep-alive; it doesn’t know about sanctum-admit’s pool. When two reflex layers have overlapping write authority on the same target (LM Studio’s loaded model), one of them must defer to the other. We taught the guardian to defer.

The fix is one line in ~/.sanctum/config/lmstudio-guardian.conf:

EXPECTED_MODEL=qwen2.5-coder-14b-instruct
EXPECTED_MODEL=

Empty value puts the guardian in monitor-only mode: it still tracks LM Studio app health and probes the API, it just doesn’t auto-load anything. coder-14b is now an explicit on-demand load:

sanctum-admit release sanctum-mlx \
  && sanctum-admit load lmstudio-coder-14b

Ogilthorp3/sanctum-config@6809aa6.

The voice canary’s tight 20s

A symptom downstream of the unwanted guest. The Yoda card on the Holocron showed the canary at 45.8% pass rate over 24 hours, against an 88.5% rolling-7d baseline. Every failure mode was the same string: timeout after 20.0s (audio=never). Successes broke into two groups: cache-served (3-9s first audio) and cold (13-20s first audio under load).

Memory pressure from the over-budget pool was making cold first-audio creep past the 20-second canary timeout. Once we cleared the budget, cold runs fit comfortably under the threshold again. Nothing was wrong with the canary — it was honestly reporting a cascade that started two sections up. Fix the guest, and Yoda stops timing out.

Pre-reboot

A clean snapshot was saved to ~/.sanctum/state/pre-reboot-2026-05-02.txt. The briefing queue was flushed (it had been quiet anyway after retiring signal-proxy). The guardian’s monitor-only switch survives reboot — the config re-reads on each tick. After reboot, the launchagents respawn, sanctum-mlx auto-loads, coder-14b stays unloaded by default, and the pool starts the day with room to breathe.

What this trip taught us

• Catalog rot is a class of failure all its own. Half of today’s red sectors weren’t broken — they were ghosts of architectures retired weeks ago, still being probed because nobody had written the obituary.
• The Holocron’s truth is exactly what the watchdog tells it. When a sector reads Unknown, the question isn’t “what’s wrong with that service” but “is the watchdog asking about it under the right name?”. A missing yaml is invisible until you go looking for it.
• Two reflex layers writing to the same target is a coordination problem, not a code problem. Resolution belongs in config, not in mutual locks: one layer commands, the others observe.

Most of today’s red was shadows — obituaries for architectures retired weeks ago, still being probed because nobody had written the death notice. The haus is quieter now, and the crystal reads honest-green — which, unlike the grey, means exactly what it says.
