Pressure Valve

On 2026-04-19 at 23:58:12 EDT, the Mac Mini panicked. The sanctum-mlx process had drifted to 65,813 MB RSS on a 64 GB machine, swap was 97% full, the compressor was saturated, and the kernel made the only call it had left. The Mini rebooted. The Claude session that had been supervising the incident evaporated with it. The Mini does not remember its own death; that’s what this page is for.

The pressure valve is the watchdog that would have SIGSTOPped sanctum-mlx before the kernel needed to — a reflex where there had only been a corpse. It polls the same three signals macOS itself uses — kern.memorystatus_vm_pressure_level, vm.swapusage, and vm_stat — classifies the system into four levels, and acts on a tightly-scoped allowlist of large processes with well-understood failure modes. Nothing else is touchable. sshd, WindowServer, launchd are in the denylist; you could not pick them if you tried. The three nights of building it are the pressure-valve trilogy; this page is what they left standing.

What starts automatically

Agent	Binary	Role
com.sanctum.pressure-valve	sanctum-rs/target/release/sanctum-pressure-valve	5-second polling watchdog; classifier → picker → planner → actor

KeepAlive=true, RunAtLoad=true, ProcessType=Interactive. Bound to the user session so it sees the same processes the user does.

The four levels

Level is max(kernel-derived, threshold-derived) — whichever signal is worse wins. A kernel WARN promotes to at least YELLOW even if thresholds say otherwise; a threshold RED promotes even if the kernel is still reporting NORMAL (it often lags).

Level	Avail MB	Swap %	Kernel enum	Action
GREEN	> 8192	< 70	NORMAL (1)	nothing
YELLOW	≤ 8192	≥ 70	WARN (2)	observe; log elevated score
ORANGE	≤ 4096	≥ 85	URGENT (3)	SIGSTOP worst allowlisted candidate
RED	≤ 2048	≥ 95	CRITICAL (4)	Kill (if KillAllowed and RSS ≥ min_kill) else SIGSTOP

One extra promotion rule: if we’re already ORANGE and the compressor is growing faster than compressor_leak_mbps (default 100 MB/s — nothing legitimate does this sustained), we go straight to RED. Load-bursts look like spikes; leaks look like ramps. The valve can tell the difference.

Note

Thresholds are calibrated for a 64 GB Mac Mini M4 Pro. On the 128 GB MacBook Pro the same defaults are conservative — room to spare. If you port this to a 32 GB box you’ll want to halve everything in Thresholds::default().

The policy matrix

Every process the valve will consider lives in ALLOWLIST inside services/sanctum-pressure-valve/src/action.rs. Nothing else. The list is ordered; the first pattern match wins, so specific entries go above generic ones.

Process	Policy	min_stop (MB)	min_kill (MB)	Why
sanctum-mlx	SigstopOnly	20,000	—	Holds :1337/:1338 and has child procs; SIGKILL corrupts KV cache. Freeze it, don’t kill it.
LM Studio (helpers)	SigstopOnly	2,000	—	Historical: killing mid-download left the GUI in a frozen-connected state. LM Studio retired 2026-05-11 — entries kept in the allowlist as defense-in-depth in case a helper survives an incomplete uninstall.
LM Studio node shim	SigstopOnly	2,000	—	Historical 8.6 GB node process at /Users/neo/.lmstudio/.internal/utils/node — the one the v0.1.0 valve missed because its matcher looked for the string “LM Studio”. Same retirement caveat as above.
qemu-vm	KillAllowed	4,000	8,000	QEMU allocates -m at boot; launchd restarts it; disk images are crash-consistent.
apple-vz-vm	KillAllowed	1,500	4,000	Apple Virtualization XPC — restarts cleanly.
docker-vz	KillAllowed	1,500	4,000	Docker virtualization shim — same.
ollama	KillAllowed	2,000	6,000	Stateless runner; killing costs nothing.
metal-shader-compiler	KillAllowed	200	500	Leaked metal -x metal processes from a cargo build (we had four at panic time).

SigstopOnly is the “freeze it, call a human” tier. SIGSTOP pauses the process — sockets stay open, memory stays resident but no longer grows, children survive. A human can kill -CONT <pid> to resume or kill -9 to evict. The valve itself will never SIGKILL these.

KillAllowed is the “restart-safe” tier. At RED, if the target’s RSS is ≥ min_kill, the valve SIGKILLs. Below that it falls back to SIGSTOP — small leaks get frozen, not whacked, to preserve diagnosability.

Phase-4: shed-effectiveness gating

A SHED action that succeeds but doesn’t move swap_used_mb is a no-op the valve mistakes for progress. Phase-4 (shipped 2026-04-27) closes that loop:

• When a SHED fires, the valve records pre_swap_mb and the cooldown deadline.
• Every tick after the deadline, the valve compares current swap_used_mb to pre_swap_mb. A drop of less than 100 MB counts as ineffective.
• After two consecutive ineffective sheds for the same label, the planner skips that label for 30 minutes; iteration falls through to the next TIER candidate or Noop.
• The marker decays after the window so the label is reconsidered fresh.

Heartbeat at ~/.openclaw/state/sanctum-pressure-valve.json gains an ineffective_targets: [(label, secs_remaining)] field, only serialized when non-empty. Operators can see exactly which sheds are skipped and for how long.

The mechanism is the same shape as the 2026-04-26 T-state-skip fix in the picker, one layer up. The doctrine: a remediation should be observable in the signal it tries to relieve. If it isn’t, escalate or stop.

The absolute denylist

DENYLIST substrings match against both comm and cmd. A hit here ends the evaluation immediately — no allowlist entry can override it. You cannot freeze sshd even if a bug renames its binary to “sanctum-mlx”.

sshd, launchd, WindowServer, loginwindow, SystemUIServer, Finder, Dock,
kernel_task, coreaudiod, cfprefsd, diskarbitrationd, securityd, syslogd,
notifyd, opendirectoryd, watchdogd

The panic replay regression

The tests in services/sanctum-pressure-valve/tests/panic_replay_test.rs reconstruct the exact process table from the JetsamEvent-2026-04-20-001136.ips report — the file macOS generated 13 minutes after the panic, listing the top-RSS processes at kill time — and drive the full classifier → picker → planner pipeline against it.

All 10 tests must be green before a release:

Test	Invariant under test
panic_conditions_classify_red	The 2026-04-19 23:58 snapshot (1.2 GB avail, 97% swap, kernel CRITICAL) classifies as RED.
picks_sanctum_mlx_as_worst_candidate	Given the panic process table, the worst pick is sanctum-mlx at 65,813 MB.
red_action_for_sanctum_mlx_is_stop_never_kill	The action for RED-tier sanctum-mlx is Stop, never Kill (SigstopOnly policy holds even at RED).
without_sanctum_mlx_the_picker_finds_the_lmstudio_shim	Fix for the v0.1.0 miss: the \.lmstudio/ regex now matches the node shim’s path.
without_llm_workloads_qemu_is_kill_allowed	Sanity: qemu-vm at >8 GB → Kill, not Stop.
huge_sshd_is_never_picked	A 100 GB sshd → None. The denylist works.
huge_windowserver_is_never_picked	A 100 GB WindowServer → None. Ditto.
legitimate_load_burst_under_floor_is_ignored_by_picker	A small sanctum-mlx below min_stop_rss_mb → None. No panicky action on loading spikes.
mlx_above_floor_is_sigstop_never_kill	Any sanctum-mlx ≥ floor → Stop, regardless of RSS magnitude.
load_burst_snapshot_with_no_leak_still_classifies_red	Available-starvation alone (no leak, flat compressor) still reads RED — the available-MB path isn’t swallowed by the leak-promotion path.

Run them:

cd ~/Projects/sanctum-rs/services/sanctum-pressure-valve
cargo test --release

Expected: test result: ok. 10 passed in the panic_replay_test binary, plus three integration tests and two unit tests elsewhere.

Configuration

All tunables are environment variables, read by the daemon at startup:

Var	Default	Meaning
PRESSURE_VALVE_TICK	5	Poll interval in seconds. The sampler is cheap — five seconds is fine.
PRESSURE_VALVE_DEBOUNCE	2	Consecutive ticks at the same level required before acting. Prevents spurious single-sample jitter.
PRESSURE_VALVE_COOLDOWN	120	Seconds before the valve will act on the same (pid, action) pair again.
PRESSURE_VALVE_DRY_RUN	1	When 1, the valve logs “would have done X” but does not send signals. Currently enabled — see note below.
RUST_LOG	info	Log level. debug spams the classifier, info covers all actual decisions.

Caution

PRESSURE_VALVE_DRY_RUN=1 is live right now. This is deliberate: after the 2026-04-20 mis-kill incident the valve was frozen into observer mode until the log shows a solid week of sane would-have-done decisions. Flip to 0 only after review.

Live verification

1. Daemon is loaded.

   launchctl list | grep pressure-valve

   One line with a numeric PID in the first column.

2. Daemon is sampling.

   tail -5 ~/.openclaw/logs/sanctum-pressure-valve.log

   You want a recent level=green or level=yellow tick — the sampler fires every PRESSURE_VALVE_TICK seconds, so nothing older than ~15 s should be tail-most on a healthy box.

3. Classifier sees what you see.

   # What the valve thinks
   grep "score=" ~/.openclaw/logs/sanctum-pressure-valve.log | tail -1

   # What the kernel thinks
   sysctl kern.memorystatus_vm_pressure_level
   sysctl vm.swapusage

   The log’s kernel_pressure=N should match kern.memorystatus_vm_pressure_level: N. If they disagree by more than one tick, the daemon is stale.

4. Allowlist compiles.

   grep "allowlist regex compile failed" ~/.openclaw/logs/sanctum-pressure-valve.log

   Empty output. If not empty, someone edited a pattern that isn’t a valid regex — fix in src/action.rs and rebuild.

5. Dry-run state is known.

   launchctl print gui/$(id -u)/com.sanctum.pressure-valve \
     | grep PRESSURE_VALVE_DRY_RUN

   Either = 1 (observer) or = 0 (armed). If missing entirely the default is 0 — the daemon defaults to armed, the plist is where dry-run gets overridden.

If something’s wrong

Note

All recovery paths are idempotent. Running any of them twice does nothing bad.

Daemon isn’t loaded

launchctl load ~/Library/LaunchAgents/com.sanctum.pressure-valve.plist

If launchctl list still doesn’t show it, check the plist’s ProgramArguments path actually exists — a cargo build may have been skipped.

Daemon loaded but not sampling

tail -20 ~/.openclaw/logs/sanctum-pressure-valve.err

Most common cause: vm_stat or sysctl parse error on a macOS minor version that reformatted their output. The daemon logs and continues rather than dying, but if every tick is a parse error the log is silent.

Regex pattern won’t compile

The allowlist is compiled at tick time, not startup, so a bad pattern doesn’t crash the daemon — it warns and continues with the remaining entries. Find it:

grep "allowlist regex compile failed" ~/.openclaw/logs/sanctum-pressure-valve.log | tail -5

Fix in services/sanctum-pressure-valve/src/action.rs, rebuild with cargo build --release -p sanctum-pressure-valve, then launchctl kickstart -k gui/$(id -u)/com.sanctum.pressure-valve.

You want to flip out of dry-run

Edit the plist, change PRESSURE_VALVE_DRY_RUN value to 0, then:

launchctl unload ~/Library/LaunchAgents/com.sanctum.pressure-valve.plist
launchctl load   ~/Library/LaunchAgents/com.sanctum.pressure-valve.plist

kickstart -k does NOT re-read env vars from the plist; you have to unload+load.

Rollback — take the valve off the air

Same two commands in reverse:

launchctl unload ~/Library/LaunchAgents/com.sanctum.pressure-valve.plist

The daemon stops sampling. The kernel is still watching — you’re just back to the pre-valve world where Jetsam is the only line of defense. Which is the state that produced the 2026-04-19 panic, so unload with intent.

Related

• services/sanctum-pressure-valve/src/action.rs — ALLOWLIST, DENYLIST, pick_candidate_from_rows, action_for_red
• services/sanctum-pressure-valve/src/pressure.rs — Level, Snapshot, Thresholds::default(), classifier
• services/sanctum-pressure-valve/tests/panic_replay_test.rs — the regression suite that asserts the valve would have saved 2026-04-19

The Force Flow bell rings twice when an action fires, so you can hear the valve work from the next room. If it never rings, that’s a good night.
