Hive Topology

You open a shell on the road and type ssh manoir. It works. Two weeks later you type the same string from the chalet Mini and it works again. Nobody renumbered a subnet. Nobody published a Tailscale subnet route. The laptop did not need a special VPN profile for “vacation mode.” The string was the product.

The failure mode this chapter exists to prevent is the opposite story: one flat 10.0.0.0/24 fantasy spanning two basements, a Firewalla that advertises the wrong site as a mesh, and a fine-tuned model that hardcodes “the Mini is always .10” as if there were only one Mini in the world. Multi-site Sanctum is a fleet of complete organisms, not one organism with two basements.

The product in one sentence

Same design map at every site. Cross-site by node name only. Never merge L3.

Plane	What it is	What it is not
Body	Per-site LAN design map (.1 FW · .2 Orbi · .3 HA · .10 Mini)	A global address space
Hive	Tailscale + MagicDNS + nodes.* roster + vault / agents	Subnet routes of whole hauses
Mind	Shared topology priors for prompts and fine-tunes	Per-haus fork of those priors (not the P5 predictor)

Open mesh (signed LoRA champions between hauses) is a sibling plane — see Champion Gate. Do not overload it as the multi-site control plane.

Body — isomorphic enclave

Every site reuses the same local map. Numbers collide across sites on purpose and stay safe because those prefixes are never advertised as Tailscale subnet routes.

Role	Design IP	Identity pin (Firewalla)
Firewalla	10.0.0.1	gateway
Orbi AP	10.0.0.2	model / hostname match
HA Green (when present)	10.0.0.3	homeassistant
Mini / brain	10.0.0.10	model + Bonjour / dhcp name

Those 10.0.0.x values are the design map (documentation-range style anchors for the isomorphic body). Live LAN discovery still goes through endpoint resolution — the hive never treats them as cross-site addresses.

Implementation: identity-rebind in openclaw-skills/firewalla-toolkit (config/identity-pins.json, install scripts on each box). Match by durable identity, not MAC, so Private Wi‑Fi rotation cannot orphan the pin. Sites are separated by Firewalla lan_uuid so manoir’s pins never apply on the chalet Purple and vice versa.

Hive — name-only nervous system

Cross-site traffic uses node names. Naming is a product surface.

sanctum node names             # cheat sheet
sanctum node list
sanctum node resolve chalet    # preferred MagicDNS stem
sanctum node whoami            # .node_id must equal roster key
ssh neo@manoir                 # MagicDNS when the machine is named manoir

Do	Don’t
manoir, chalet, mbp	Display codes (MM64, MBP128) as addresses
manoir-fw, manoir-ha	Dual live names without a deliberate recovery map
Agent names for agents (ahsoka)	Agent names as Tailscale hosts
Resolve at call time	Hardcoded 100.x (endpoint resolution)

Naming contract (Apple-simple)

Jobs test: What do you call it when you talk to it? That string is the only name — roster key, ~/.sanctum/.node_id, and MagicDNS stem are the same.

Kind	Pattern	Examples
Site brain (Mini)	{place}	manoir, chalet
Mobile	{device}	mbp
Site infra on TS	{place}-{role}	manoir-fw, manoir-ha, chalet-fw
Agent	Jedi seat	yoda, ahsoka — never a TS host

# Live contract — one name, no dual identity
mbp:
  type: mobile
  tailscale_name: mbp

Legacy stems (berts-mbp, manoir-firewalla, …) may still appear in hive-names.yaml as recovery matches so a device that reappears under an old control-plane Name can be re-converged. They are not live aliases and must not be what you put in scripts.

Converging MagicDNS — apply-hive-names

Control-plane renames (the MagicDNS Name, not only the device HostName) go through the Tailscale API. The durable path is the toolkit, live via symlink:

# Live path == repo (Durability Doctrine)
# ~/.sanctum/tailnet → openclaw-skills/tailnet-toolkit
~/.sanctum/tailnet/tools/apply-hive-names.sh status
~/.sanctum/tailnet/tools/apply-hive-names.sh plan
~/.sanctum/tailnet/tools/apply-hive-names.sh apply --sync-roster

Piece	Role
hive-names.yaml	Declarative want-names + match / reject / recovery exact-map
apply-hive-names.sh	Plan / apply / status; stem comparison (FQDN → first label)
ha-check.sh	manoir-ha peer + HTTP + optional LAN probe
seed-oauth.sh	One-time OAuth client → SOPS (+ keychain cache)
tools/lib/ts-auth.sh	Shared mint; never logs secrets

Declarative SoT for names: hive-names.yaml.
Declarative SoT for API credentials: Mini SOPS store ~/.sanctum/keychain-secrets.enc.json keys tailscale-oauth-client-id / tailscale-oauth-secret. Keychain entries with the same service names are a cache for GUI sessions; headless tools prefer SOPS (ts-auth resolution order).

OAuth client scopes: ACL write + Devices › Core write (plus tags if you tag devices). Mint check:

source ~/.sanctum/tailnet/tools/lib/ts-auth.sh && ts_auth_check
# expect: auth=ok devices=200

Two Names, one machine

Tailscale keeps a device HostName (set on the node) and a control-plane Name (MagicDNS). Device-local tailscale set --hostname=… often updates both, but not always — especially when the Name was admin-set. If status shows the short name but dig still resolves an old FQDN, run apply-hive-names apply. If plan is a no-op and DNS is still wrong, the resolver is caching — not the hive.

Unit smoke (no network): python3 ~/.sanctum/tailnet/tools/test-hive-names-match.py.

Roster — instance.yaml nodes

topology:
  design: isomorphic-enclave
  hive: name-only

nodes:
  manoir:
    type: hub
    tier: primary          # primary | peer | edge
    site: manoir
    ssh_user: neo
    tailscale_name: manoir
    capabilities:
      - vault_authority
      - inference
      - ha_site

  chalet:
    type: satellite
    tier: edge
    site: chalet
    ssh_user: neo
    tailscale_name: chalet
    sync:
      hub: manoir
    capabilities:
      - local_inference
      - satellite

  mbp:
    type: mobile
    tier: edge
    tailscale_name: mbp

Field	Meaning
type	hub · satellite · mobile · sensor
tier	primary (config SoT) · peer (multi-hub) · edge
site	Design-map / identity-pins site id
tailscale_name	MagicDNS stem for sanctum node resolve
capabilities	Static offers for hive work placement

CLI surface (hive roster + routing):

sanctum node list | get | whoami | resolve | validate
sanctum node offers | can <capability> | route <capability> [--prefer local|fastest|primary|hub:NAME]
sanctum node vault-host          # primary hop for Memory Vault (name-only)
sanctum node ensure-hub | declare-peer NAME | export-council

Council-router config/nodes.json stores hive names, not drift-prone 100.x. Delivery resolves at call time. Vault hop: memory-vault/scripts/vault-hive-hop.sh or sanctum node vault-host.

Capability routing

Capability	Typical offer
vault_authority	primary hub only
inference / inference_heavy	primary + peer hubs
local_inference	satellites + mobile
ha_site	hubs with HA Green
train / mesh_seed / council	hubs

sanctum node route inference --prefer primary
sanctum node route local_inference --prefer local

Multi-hub (peer join)

Exactly one primary hub (config SoT, vault authority, adopt authority). Additional peer hubs keep the same body map and join the hive by name — no renumbering, no LAN merge.

sanctum node declare-peer montreal --tailscale-name montreal --site montreal
# On that Mac: echo montreal > ~/.sanctum/.node_id
# Deploy identity-rebind on that site's Firewalla with a new site block

1. Same local design map + identity-rebind for that site’s Firewalla.
2. Tailscale node online; MagicDNS name stable.
3. sanctum node declare-peer <name> (or hand-edit roster).
4. .node_id matches the roster key.
5. Sync policy: pull config from primary; never dual-write instance.yaml silently.
6. Offer metal via capabilities — route with --prefer hub:<name>.

Fine-tune mental model (“Sanctum-space”)

A model fine-tuned for Sanctum may assume:

1. Every site has the design roles above (when the gear exists).
2. Local .10 is this site’s Mini; other brains are named hubs/satellites.
3. Cross-site actions use node names, never guessing which 10.0.0.0/24 is which.
4. Offline satellite prefers local metal; online hive may route to primary/peer capacity.
5. Vault authority lives on the primary hub unless a capability says otherwise.

Site-specific facts (room names, people, Nuheat zones) belong in memory / RAG, not in weights that hardcode one haus’s LAN quirks.

Why not merge the mesh?

Merge L3	Hive (this design)
Must renumber at least one site	Clone site N without renumber
Subnet routers = critical path + blast radius	Failure stays in the enclave
Optimizes bare IPs	Optimizes names (the product)
Breaks “same mental model” if maps diverge	Same map → one curriculum

Subnet routes remain a special feature for dumb IoT that cannot run Tailscale — never the default architecture.

EETISMAD smoke

Letter	Proof for this feature
E2E Tested	ts_auth_check; apply-hive-names plan is a no-op when perfect; ha-check.sh; match unit test
in Sanctum-docs	This page + sidebar
Merged	openclaw-skills tailnet-toolkit + SOPS store on Mini config repo
And Deployed	~/.sanctum/tailnet symlink → toolkit; live MagicDNS stems

If plan invents renames forever, the stem comparison regressed (FQDN vs short name). If auth fails, re-seed OAuth into SOPS first, then keychain cache.
