TurboQuant Slice 4 — GPU Dequantization Scoping

The flag works. Slices 1 through 1f dragged TurboQuant from “doesn’t compile” to “ships 21× better quality at 4× compression,” and every one of those numbers is earned. What the flag cannot yet be is a default — and the thing standing in the way is embarrassingly boring. Dequant runs on the CPU. Fine for correctness validation, unshippable for production. This page is where we scoped the kill: Slice 4.

4a landed — 2026-04-19, then got rebuilt from the ground up 2026-04-24

The original 4a (Lloyd-Max key dequant ported to MLX ops, 21f230f + b469c52) measured 9.4× per-fetch versus the CPU reference — but end-to-end on the production Qwen3.6-35B-A3B MoE the win didn’t translate, eaten by per-step kernel-launch overhead and concat-grow cost. So we threw it away. The 2026-04-24 rebuild flipped the premise: stop compressing keys entirely (~4 MB/layer of bf16 K at T=2048 is nothing on a 64 GB Mini) and hand-write a fused Metal kernel that dequantizes V inline during attention, so V never materializes. It ships as sdpa_dequant_v in services/sanctum-mlx/src/turboquant/attention_kernel.rs, and on the MBP M4 Max bench (vanilla MoE) lifts the dev-grade Slice-1 path from 62.38 to 75.64 tok/s (+21.2%), ~5% under the 79.42 no-TurboQuant baseline. The flag stayed off until a confirmed winner earned the flip — --turboquant now ships on in the production plist, per the shipped-architecture page. This page is the planning-time record; the architecture that shipped lives there.

The current bottleneck

Every call to CompressedKVCache::update_and_fetch, inside the decode loop:

step t: quantize new K,V  → push to Vec<CompressedHeadKV>
step t: rebuild_f32       → dequantize ALL T stored tokens,
                            build flat Vec<f32>, ship to Metal
step t: Array::from_slice → fp32→bf16 cast on GPU

Three problems, in priority order:

1. O(T²) CPU work across a generation. Each step rebuilds every prior token — at T=1000, 500,000 per-vector CPU dequants.
2. CPU↔GPU bounce every step. The f32 Vec lives in host memory; Array::from_slice ships it back to the GPU. Full round-trip per decode step.
3. No kernel fusion. Even with GPU dequant, the path is dequant → cast → SDPA: two Metal dispatches where one fused kernel could do dequant + Q·Kᵀ + softmax + ·V in a single shot.

At realistic context lengths (1k–4k), CPU dequant dominates — which is why --turboquant ships a “dev-grade CPU dequant, expect throughput regression” warning at startup.

The three tiers

Three ways to move dequant onto the GPU, in ascending order of effort and nerve — the hero image up top renders them as a hand-file, a lathe, and a particle-beam etcher, three machinists working the same crystalline part. Qui-Gon, who never met an idle cycle he could forgive, would insist we climb the ladder one rung at a time and measure between each. We meant to.

4a — MLX ops (no Metal)

The practical production unlock. Replace every CPU-side dequant with MLX ops, which run as Metal kernels automatically. CompressedKVCache stores mlx_rs::Array instead of Vec<u8> / Vec<half::f16>: quantize produces Arrays, concatenate with mx.concatenate, dequantize with mx.astype + mx.multiply + mx.add (all Metal-backed).

Key path (rotation + per-vector affine):

on write:
  normalize_and_rotate :: Array → Array      # matmul against H_d, O(d²) on GPU
  find scale/zero      :: Array → (Array,Array) # mx.min, mx.max
  quantize             :: Array → Array      # (x - zero) / scale, round, clamp

on read:
  dequantize + unrotate :: Array → Array     # reverse of the above

No per-token CPU loops, no Vec allocation, no host round-trip. Value path: mlx_quantize / mlx_dequantize already exist as C FFI → Metal kernels doing exactly our per-group affine scheme — a drop-in for quantize_value_group / dequantize_value_group.

Effort: 200–400 LOC net. Risk: Medium-low — algebra unchanged; watch Array layout quirks (the flatten stride bug from Slice 1) and dtype drift vs the CPU path; re-run the 3-arm A/B first. Wins: O(T)→O(1) amortized; zero round-trips; 3–6× the current path at 2k, within spitting distance of fp16.

4b — mx.compile fusion

The mid-tier polish. Once 4a lands, wrap dequant + SDPA in mx.compile, which traces a function of MLX ops into a graph and emits one fused Metal kernel — no shader-authoring:

mx.compile(|cache_state, q| {
    let k = dequant_keys(cache_state);
    let v = dequant_values(cache_state);
    fast::scaled_dot_product_attention(q, k, v, scale, mask)
})

One kernel call — dequant + SDPA, no full-K/V materialization.

Effort: 50–150 LOC on top of 4a. Risk: Medium — mx.compile has footguns around shape variation (decode increments T every step) and may re-trace at new sizes; if 4a is already <2× fp16, 4b is polish. Wins: single dispatch per step; potentially 20–40% faster than 4a at small T.

4c — custom Metal kernel

The maximum-effort play. A Metal shader takes quantized K/V buffers + rotation metadata + scales + zeros and computes the full SDPA inline: read quantized bytes, dequantize lane-local, multiply by Q, softmax, write the output — dequantized tensors never leave registers. Kills both the O(T²) compute AND the bandwidth of moving dequantized K/V through GPU memory.

Effort: 800–2000 LOC: .metal source inside mlx-sys, build glue to compile a .metallib, host-side Rust dispatch, correctness tests against 4a, benchmarks.

Risk: High. Metal shader authoring is a whole new skill layer; Apple’s debugging tooling is Xcode-bound and UI-heavy; subtle bugs hide for weeks. Don’t start 4c until 4a ships and profiling gives a concrete reason the MLX path isn’t enough.

Wins: Single dispatch; zero bandwidth on dequantized tensors; plausibly 1.1–1.3× the fp16 reference, because quantized K/V is smaller in DRAM — so memory-bound attention gets faster with good compression. Against its own “don’t start this until profiling forces it” hedge, this is the tier we shipped.

Recommended ordering

1. Ship 4a first. Real production throughput, removes the “dev-grade” warning, measurable on a wikitext decode loop.
2. Measure before 4b or 4c. Profile at 2k and 4k. Within 2× of fp16 → 4b/4c are nice-to-haves; still 5× slower → 4b is next.
3. 4c only if 4b hits a wall. mx.compile is Apple’s own fusion answer; hand-rolling Metal to beat their compiler is a long bet.

The ordering was right; the world wasn’t. 4a-as-ported didn’t clear the bar, 4b never happened, and we went straight to a 4c-shaped rebuild (see the Aside). And even at ~5% under baseline, the flag still didn’t flip right away: a passing throughput bar is necessary, not sufficient — the default waited on a confirmed quality winner across architectures, a slower clock that has since run out.

Contracts we DON’T want to break

• Quality is already paid for. Slices 1a–1f landed at Δppl ≤ 0.01 on Qwen3.5, ≤ 0.17 on Qwen2. Any perf change that moves those past measurement noise is a bug, not a win.
• The KeyValueCache trait is a load-bearing boundary. Slice 4 changes CompressedKVCache internals only — never update_and_fetch’s signature or the KeyValueCache + Default bound the model impls depend on.
• Bypass modes stay. BypassMode::{IdentityPassthrough, BridgeOnly} caught a stride bug on day one and a mislabeled A/B on day two. The short-circuits keep working through any refactor.

Rough timeline (planning-time)

• 4a implementation: 1 focused day — rewrite cache.rs storage from Vec-based to Array-based, both pipeline halves speaking mlx_rs::Array end to end.
• 4a validation: 2–3 hours — re-run turboquant_ppl; any Δppl change > 0.01 is a port bug.
• 4a profiling + doc: half a day — before/after latency + memory, write the GPU-dequant section into turboquant-kv-compression.mdx.

We pencilled in ~2 days to GPU-port the existing math. What shipped was a from-scratch rebuild on the opposite premise. The estimate wasn’t wrong about the port; the port just wasn’t the answer.

Where the work lives

• services/sanctum-mlx/src/turboquant/cache.rs — the main target.
• services/sanctum-mlx/src/turboquant/quantizer.rs — migrate quantize_value_group to an Array-based signature (planning-time this also listed a key-side quantize_key_affine; the rebuild deleted the legacy key path in 37853d8, so only the value side survived)
• vendor/mlx-rs/mlx-rs/src/ops/ — expose mlx_quantize / mlx_dequantize in the Rust wrapper. The planning-time grep 'pub fn quantize' came up empty, and still does: what landed is quantize_device, not a bare quantize, so a thin safe wrapper is still the first step.
• Validation lives in tests/turboquant_ppl.rs plus the turboquant_truncate_test / drift_probe bins — no bench/ dir was ever created.

The map and the territory

Qui-Gon’s ladder was the right ladder. The world just refused to climb it: 4a-as-ported missed the bar, 4b never happened, and the winner turned out to be a 4c-shaped kernel built on a premise the plan never entertained — stop compressing the keys at all. So why keep a planning doc the shipping code now contradicts on nearly every line? Because a plan that survives contact with reality teaches you nothing, and this one did not survive. The escalation still held even when we skipped straight to the particle beam — The Carmack Optimization is the same instinct pointed at training, and Sanctum-MLX is the Rust server all of this fuses into. The shipped architecture is the destination; this page is the map we drew before we knew the roads had moved.

References

• MLX fast.scaled_dot_product_attention — the optimized kernel we’re feeding
• MLX quantize — the GPU primitive Slice 4a leans on
• mx.compile — Apple’s kernel fusion path for 4b
• TurboQuant KV Compression — the full pivot writeup, plus the Slice 1a–1f validation discipline
