2026-07-16 — The reply that never left the bridge

The most important interface in Sanctum is a Signal thread with Yoda. When it goes quiet, every other green dashboard is a lie.

On 2026-07-16 the operator watched our outbound probes land on his phone and still got no answers to the messages he sent back. Health said OK. The bridge was “up.” Yoda’s texts arrived. Bert’s never did. The silence was inbound-only — the worst kind, because nothing was on fire and nothing was logged loud enough to notice.

Symptom

Every check that could be green was green. The one that mattered was not.

Check	Result
signal-cli / socat / yoda-chat-proxy	Up
Outbound send (openclaw message send, agent --deliver)	SUCCESS
Operator receives Yoda-originated texts	Yes
Operator texts Yoda	No reply
Proxy recent_events	Contained dataMessage from Bert ("hi")
openclaw-gateway journal after that hi	No agent run

Outbound green plus inbound mute is the tell: the transport works, and something in the inbound parser or the channel gate is quietly eating messages. The hi reached the proxy. It just never became an agent run.

Root causes (stacked)

Two independent faults, either one enough to swallow a message on its own. We fixed the first, watched the provider start, and still heard nothing — which is how we found the second.

1. Channel disabled on the live gateway

On the VM, ~/.openclaw/openclaw.json had Signal switched off:

"channels": {
  "signal": {
    "enabled": false,
    "httpUrl": "http://127.0.0.1:5150",
    ...
  }
}

The Mac Mini host config still had Signal enabled, which is exactly what made this so convincing — someone glancing at the twin config would swear it was on. But the gateway that matters runs on the sanctum-vm, and that copy was off. Enabling it made the provider start ([signal] starting provider) and still did not process a single message. One fault down, and the room was just as quiet.

2. SSE payload shape mismatch (the silent drop)

The yoda-chat proxy emitted its receive events like this:

event: receive
data: {"method":"receive","params":{"envelope":{...},"account":"..."}}

OpenClaw’s Signal monitor reads them like this:

payload = JSON.parse(event.data);
const envelope = payload?.envelope;  // undefined when nested under params
if (!envelope) return;               // silent drop

The envelope OpenClaw wanted at the top level was nested one layer down, under params. So every real inbound envelope arrived at the proxy, was faithfully recorded in /api/v1/status, and was then discarded by OpenClaw without a log line loud enough to page anyone. The bridge was not down. It was reading the mail and filing it in the wrong drawer.

The fix flattens the SSE write path so the data field is the signal-cli params object itself:

# data MUST be the signal-cli params object (top-level envelope)
payload = json.dumps(params if isinstance(params, dict) else {"value": params})
self.wfile.write(f"event: {method}\ndata: {payload}\n\n".encode("utf-8"))

Proof after the fix: a synthetic inject produced typing, then a send, then [signal] delivered reply to +15555550100. The operator confirmed a live reply on his phone. The round trip closed for the first time in the incident.

Self-heal (R2D2 / signal-link-sentinel)

A fix that only a human can reapply is a fix with a half-life. The Mac-side signal-link-sentinel — wrapped by R2D2 recipe heal-yoda-signal-link — now treats inbound readiness as first-class, so both of the day’s faults have a named state and a named heal.

State	Heal
SIGNAL-CHANNEL-DISABLED	Re-enable channels.signal + restart gateway
SSE-CONTRACT-BROKEN	Re-apply SSE payload shape from goldens + restart
GATEWAY-DOWN	Restart openclaw-gateway + yoda-chat-proxy
(existing) SIGNAL-CLI-DOWN / BRIDGE-DOWN / VM-CONSUMER-DOWN	kickstart / doctor

The sentinel gathers its facts from a probe script that lives on the VM and is called over SSH:

~/.openclaw/yoda-chat/scripts/inbound-readiness.py

The tracked golden copies live under sanctum-config, ready to re-apply after a rebuild wipes the VM’s working copy:

~/.sanctum/yoda-chat/   # sanctum-config
  scripts/inbound-readiness.py
  patches/proxy.py
  patches/doctor.py
  apply-inbound-goldens.sh

Operator commands

Four commands cover the whole surface — check readiness, force the heal R2D2 runs, redeploy goldens after a rebuild, and ask the VM for the raw facts:

# Readiness (Mac)
python3 ~/.sanctum/sentinels/signal-link-sentinel.py --check

# Force heal (what R2D2 runs)
bash ~/.sanctum/scripts/r2d2/heal-yoda-signal-link.sh yoda-signal-link

# Re-deploy goldens to the VM after a rebuild
~/.sanctum/yoda-chat/apply-inbound-goldens.sh

# VM inbound facts only
ssh yoda 'python3 ~/.openclaw/yoda-chat/scripts/inbound-readiness.py'

Healthy inbound facts come back looking like this — five booleans, all true, or the channel is not really up:

{
  "signal_channel_enabled": true,
  "sse_contract_ok": true,
  "gateway_running": true,
  "gateway_sse_subscribed": true,
  "proxy_ok": true
}

Lessons

1. Outbound success is not inbound health. Always require a dataMessage → agent run → reply chain for the primary channel.
2. The gateway config on the VM is the source of truth for Signal, not the Mac Mini’s twin openclaw.json. The twin is the decoy.
3. Silent drops are worse than crashes. If a monitor early-returns on a missing field, log at warn with the raw payload shape once. A crash pages you; a silent return lets you sleep through it.
4. Liveness is not readiness. Process up plus port open is necessary; channel enabled plus SSE contract plus subscriber connected is sufficient. The lineage is the rest of the bridge — The Holocron Bridge for how yoda-chat is wired, and Signal troubleshooting for the layers below this one.

For an incident that never threw an error, the receipt is small: a text goes in, an agent runs, a reply comes back. The sentinel now refuses to call the channel healthy until that whole round trip completes — because a bridge that only carries traffic one way is not a bridge, it is a very convincing green light.
