2026-08-07: Two Dials, One Bridge

The banner looked like a routing policy failure: ROUTE claude-fable-5 → claude-best-pro (local · claude-opus-4). The reflex was familiar — wrong account, Team vs Max, proxyd rewriting Opus, e2e lying. We checked each of those first. They were all wrong. The fire was one door upstream, with two dials on it.

What it was not

Live OAuth against the Mini’s token said personal Max: org type claude_max, tier default_claude_max_20x, active org the personal Max subscription — not the Team orgs that also appear as memberships on the same account. Fable and best-pro both pointed at the same Max bridge on :3456 with different api_model values. When the path worked, stream probes returned model: claude-fable-5 with no ROUTE banner. Account type was a red herring.

The daily light e2e stayed green the whole time. It only checks format contracts with empty messages — no inference, no seating assert. That is how you get a green monitor and a red session in the same hour.

The two dials

claude-max-api-proxy has two independent concurrency fences:

Env var	Where	Default if unset	What it gates
CLAUDE_MAX_CONCURRENCY	routes.js semaphore	2	HTTP requests that may enter the bridge
CLAUDE_MAX_SUBPROCESS_CONCURRENCY	manager.js gate	12	CLI subprocesses after a request is admitted

The LaunchAgent only set the second. So the real limit was two concurrent Claude CLI jobs, while the subprocess dial advertised twelve. Long council and agent claude --print sessions held both slots. Everything else queued. Non-stream waits for full completion — queue time became TTFB — clients timed out at 60s — seat error rates climbed — proxyd’s fallback ladder stepped from fable to best-pro (same bridge, Opus alias). The ROUTE banner was honest: fable failed, next rung answered.

Lifetime counts backed it: hundreds of subprocess exits with code 143 (SIGTERM from the manager timeout path) sitting next to clean zeros. Under load, non-stream hung. Idle, a short pong completed in about six seconds and seated fable.

The fix

Set both dials in the live Mini LaunchAgent and bootstrap (not merely kickstart — env is only re-read on load):

<key>CLAUDE_MAX_CONCURRENCY</key>
<string>4</string>
<key>CLAUDE_MAX_SUBPROCESS_CONCURRENCY</key>
<string>12</string>

Canonical path: ~/.sanctum/launchagents/live/com.sanctum.claude-max-proxy.plist (symlinked into ~/Library/LaunchAgents/). Landed as sanctum-config@84451aa. After bootstrap, launchctl print and ps eww both showed CLAUDE_MAX_CONCURRENCY=4.

Four is deliberate: enough headroom for a short operator probe while a long agent turn runs, without returning to the unbounded spawn storm the original 2026-06 concurrency patch was written to stop. Host-tools policy for what may land on that bridge still lives in proxyd host-tools — concurrency is how many may land at once; host-tools is what is allowed to land there.

What e2e learned

Light mode still owns plumbing and Anthropic-native error shape. Full mode now owns the truth that light cannot see:

• Mini: proxyd-fable-seat-nonstream / stream — real short completion; FAIL if x-sanctum-seated is not fable; WARN if seated but slower than 45s (queue smell).
• MBP tunnel: tunnel:fable-seat-* — same contract through https://127.0.0.1:4040.
• Bridge knobs: bridge-concurrency-knobs — WARN if routes concurrency is unset or under 4.
• SIGTERM ratio: sample of last 200 process closes; clean/rotated log is PASS, not a missing-signal WARN.
• Refresh horizon: FAIL under 1 day, WARN under 3 days, PASS with horizon in detail when longer (the old under-7 WARN fired for a week of healthy live tokens).

Scripts live in sanctum-mbp (scripts/proxy-e2e.sh, scripts/proxy-e2e-mini-probes.sh), symlinked from ~/.sanctum/scripts/ on the MBP.

Operator checklist

# Bridge env (must show CONCURRENCY=4)
launchctl print gui/$(id -u)/com.sanctum.claude-max-proxy | grep CLAUDE_MAX

# Seat a real fable turn through the tunnel
curl --cacert ~/.sanctum/certs/mini-proxyd-ca.crt -sS -D- \
  -H 'content-type: application/json' -H 'anthropic-version: 2023-06-01' \
  -d '{"model":"claude-fable-5","max_tokens":16,"messages":[{"role":"user","content":"pong"}]}' \
  https://127.0.0.1:4040/v1/messages | grep -i x-sanctum-seated

# Full chain (inference burns a few Max tokens)
~/.sanctum/scripts/proxy-e2e.sh --full

After a concurrency change: bootstrap the LaunchAgent, do not only kickstart. After a long incident: heal sticky seat error windows with a handful of short successful fable completions, or restart proxyd when you have daemon privileges — exponential decay alone is slow.

Two dials, one queue

Raising only CLAUDE_MAX_SUBPROCESS_CONCURRENCY does nothing if the routes semaphore is still two. The large dial is a spare key to a door the small dial already closed. Read both env vars on the live process, not the comments in the patch script.

Landing

The ROUTE banner was never inventing a diversion. It was reporting that fable could not get a slot on a bridge whose public concurrency dial said twelve and whose private one said two — the same lesson as the day the proxy was never the problem: believe the router, then measure the queue behind the door it points at. Turn the small dial. Assert seating on real completions.
