2026-05-12: The Kernel Needed Two Tokens

Same prompt. Warm cache. Different answer. The prompt cache had shipped on a feature branch two evenings earlier, and it was quietly lying — not every turn, but reliably enough that the cathedral’s canary drift probe caught it before any operator did. We pushed the branch and left it in the freezer overnight, on the theory that a cleaner head finds the bug in the morning. A cleaner head did. The bug was not where any of us were looking.

1. What didn’t work

The original implementation cached the model’s KV state per turn so a follow-up request whose prompt shared a long prefix with the previous one could skip the prefill of that prefix and dispatch only the suffix. The numbers were promising — single-digit-percent compute on hot turns — and the integration tests passed. We believed it.

Production told a different story. Identical prompts, run cold and run warm, produced different token streams. Not always — but the drift probe flags it for you long before you would notice by eye. The branch went into the freezer pending an explanation none of us had yet.

2. What was already right

Our first instinct was to suspect the cache plumbing: an off-by-one in the slice that copies KV pages from the previous request’s state into the next request’s tensors, or a mishandled mask boundary at the prefill/decode seam. Both hypotheses were testable in isolation, and — as the stress-test note two days earlier had just reminded us — a test you can build in a minute is cheaper than a theory you argue for an afternoon.

So we built two standalone binaries, both bypassing the request-handler entirely:

Test	Setup	Result
cache-roundtrip	Fill the KV cache with random tokens through a fresh forward pass, serialise to disk, reload, run a single forward and compare against an identical fresh-pass control.	Byte-identical at every one of the 48 attention layers. Both K and V tensors.
cache-prefill-suffix	Prefill prompt P once, save state, prefill P again (suffix-only on top of the saved state), compare against P cold-started.	Byte-identical at every layer except in the kernel’s output at T_q = 1.

The cache was not lying. The plumbing was correct down to the last byte at every layer of the model. Whatever produced the divergence lived after the cache, in the kernel that consumed it. That single result turned a rewrite we were about to start into a rewrite we no longer needed.

3. The divergence

The relevant kernel is MLX’s fused scaled-dot-product attention. It has two dispatch paths internally: one optimised for the single-query case T_q = 1 (decode loops, one token at a time) and one for multi-query T_q ≥ 2 (prefill, batched suffixes, anything that’s not a single-step decode). The two paths agree at every other measurable level — same arithmetic, same numerical precision, same masking — except in how they consume KV state that was placed there by a previous kernel invocation.

When the cache had been filled by the same dispatch (the current request’s prefill, then the same request’s decode), both paths behaved identically. When the cache had been filled by a previous dispatch and the suffix length collapsed to exactly one token, the single-query path produced subtly different outputs. Not garbage — the model still generated something coherent — but different enough to drift across a few tokens of a code-completion task and turn a return foo() into a return foo (or worse). You do not want to meet that failure mode in production.

The exact mechanism is internal to MLX’s vendored Metal kernel and is being filed upstream; from the cathedral’s perspective the contract is empirical: do not feed the T_q = 1 SDPA path KV state that was filled by another request.

4. The fix

One line of policy in the cache-reuse logic. When we decide the Longest Common Prefix between the current prompt and the cached one, we cap it at len(current_prompt) - 2. The suffix that actually feeds the kernel is therefore always at least two query tokens long, and the kernel always takes the T_q ≥ 2 dispatch path.

- lcp = longest_common_prefix(cached, current)
+ lcp = min(longest_common_prefix(cached, current), len(current) - 2)

The cost of leaving two extra tokens in the prefill is roughly the cost of two tokens of prefill. On a 10K-token prompt that’s a 0.02% throughput tax. What you buy with it is correctness across every cache-reuse hit — which the previous policy was paying for with a chance of silent divergence on every short-suffix turn.

Production A/B confirmed the fix in the cleanest possible way:

Policy	Result
cap = len − 1 (one-token suffix allowed, T_q = 1)	Divergence vs cold start. Drift visible at token 3–8 on most turns.
cap = len − 2 (always two-token suffix, T_q ≥ 2)	Byte-identical to cold start. Every layer, every token, every turn.

Shipped to feat/cathedral-prompt-cache @ 0123773, deployed live on the 14B coder, cache enabled.

5. Live numbers

Over the first hour of production with the fix, here is what the operator saw:

Workload	Cache-hit rate
Multi-turn code edits (same file, incremental changes)	87 %
Long-context Q&A (same document, shifting questions)	84 %
Mixed-prompt batch (autoresearch eval runs)	77 %

Numbers that justify the entire effort. The bug never reached the operator’s daily flow, because we had parked it on the branch the night before — but every short-suffix turn before today would have produced silent drift, which is the failure you do not want to discover via mysterious model regression two weeks later.

The doctrine

The cache was right. The kernel was right individually, both paths. The wrong thing was our assumption that the two paths were interchangeable at the boundary where their inputs differ in provenance. When you fuse two well-behaved code paths and ship them as one operation, the seam between them is the bug.

The fix is one line because the diagnosis was four hours. Both standalone binaries ran in under a minute; their whole value was telling us where the bug wasn’t. Subtractive triage — proving the cache plumbing innocent first — is what made the kernel boundary obvious. Skip it, and the natural first move (rewrite the cache code) produces a different bug and the same divergence, now masked.

Two tokens of suffix is a small price for a kernel you can trust. Tommy would have found the warm spot on the branch and waited for morning too — he always knew which cold was the kind that stays.

What is next

• File an upstream issue on mlx-rs / mlx with both standalone reproducers attached and the kernel-divergence trace. Same workflow Qui-Gon uses for the encoder-lifecycle issues filed earlier this month.
• feat/cathedral-pld @ dd92c65 (Prompt-Lookup Decoding) shipped the same day with self-speculation against the prompt as the draft source. PLD is unaffected by this bug because its verify-and-truncate stays intra-request — the same dispatch fills and consumes the cache, never crossing the boundary. Worth a follow-up chapter on its own.
• Streaming-path wiring for the prompt cache deferred to a follow-up commit; the sync path is live and producing the numbers above.
• The two standalone binaries (cache-roundtrip, cache-prefill-suffix) become permanent fixtures in tools/cathedral/. Future cache-touching work runs them as a precondition before deploy.
