Config System

Sanctum follows a single-source-of-truth principle: one YAML file defines the entire instance. Every service, script, dashboard, and LaunchAgent reads its configuration from this file — either directly or through generated artifacts. Secrets are stored separately in macOS Keychain and never appear in configuration files.

This is either an act of elegant simplicity or a magnificent dare. One file. One indentation error away from a very quiet house.

Configuration Hierarchy

🔍 Hover to zoom

Everything flows down from that YAML file at the top. If you’re looking for the single point of failure, you found it. If you’re looking for the single source of truth, you also found it. Schrodinger’s architecture decision: genius and catastrophe in the same file, and you won’t know which until you open it.

instance.yaml

The central configuration file lives at ~/.sanctum/instance.yaml. It contains every instance-specific value: network addresses, service ports, node definitions, feature flags, and integration settings.

~/.sanctum/instance.yaml

instance:
  name: "Manoir Nepveu"
  slug: manoir-nepveu
  domain: nepveu.name

network:
  lan_subnet: 192.168.1.0/24
  vm_subnet: 10.10.10.0/24
  gateway_ip: 192.168.1.1
  mac_bridge_ip: 10.10.10.1
  vm_ip: 10.10.10.10

services:
  gateway:
    enabled: true
    port: 1977
  home_assistant:
    enabled: true
    port: 8123
    homekit_port: 21063
  dashboard:
    enabled: true
    port: 1111
  lm_studio:
    enabled: true
    port: 1234
  council_mlx:
    enabled: true
    port: 1337
  voice_agent:
    enabled: true
    port: 8090
  # ... additional services

nodes:
  manoir:
    type: hub
    host: 192.168.1.10
    tailscale_ip: 100.112.178.25
    ssh_user: bert
    services: [gateway, home_assistant, dashboard, voice_agent]
  chalet:
    type: satellite
    host: null  # set during on-site install
    tailscale_ip: 100.112.203.32
    ssh_user: bert
    services: [gateway, home_assistant]

Tip

An annotated example file is available at ~/.sanctum/instance.yaml.example. Copy it as your starting point when creating a new instance. Read it slowly. The comments are trying to save you from the mistakes we already made.

JSON Cache

The JSON cache at ~/.sanctum/.instance.json is an auto-generated derivative of the YAML file. It exists so that shell scripts and lightweight tools can parse configuration without a YAML library.

# Regenerate the cache manually (normally automatic)
python3 ~/.sanctum/lib/yaml2json.py

The cache is regenerated automatically whenever configuration libraries detect the YAML file is newer than the JSON. Never edit .instance.json by hand — changes will be overwritten. This is not a suggestion. The file is named with a dot prefix for a reason. It is trying to hide from you.

Shell Library

Source config.sh in any Bash script to get access to configuration values:

source ~/.sanctum/lib/config.sh

Available Functions

Function	Description	Example
sanctum_get <path>	Read a value by dotted path	sanctum_get services.gateway.port
sanctum_slug	Return the instance slug	manoir-nepveu
sanctum_home	Return the Sanctum haus directory	~/.sanctum
sanctum_vm_ssh	Return the VM SSH target	[email protected]
sanctum_enabled <service>	Check if a service is enabled	sanctum_enabled voice_agent
sanctum_expand <template>	Expand {{PLACEHOLDER}} strings	See below
sanctum_whoami	Return this node’s identity	manoir
sanctum_node_get <node> <path>	Read a value from a specific node	sanctum_node_get chalet tailscale_ip

Usage Example

#!/bin/bash
source ~/.sanctum/lib/config.sh

if sanctum_enabled voice_agent; then
  PORT=$(sanctum_get services.voice_agent.port)
  echo "Voice agent running on port $PORT"
fi

VM=$(sanctum_vm_ssh)
ssh "$VM" 'systemctl --user status openclaw-gateway'

TypeScript Library

The TypeScript library provides the same capabilities for Node.js services like the command center dashboard and gateway plugins.

import { get, isEnabled, expand, vmSsh, whoami, nodeGet, getNodesByType } from './lib/config';

Available Functions

Function	Description	Return Type
get(path)	Read a value by dotted path	string | number | boolean | object
isEnabled(service)	Check if a service is enabled	boolean
expand(template)	Replace {{PLACEHOLDER}} tokens	string
vmSsh()	Return the VM SSH connection string	string
whoami()	Return this node’s identity	string
nodeGet(node, path)	Read a value from a specific node	string | number | boolean
getNodesByType(type)	List nodes of a given type	string[]

Usage Example

import { get, isEnabled } from './lib/config';

const port = get('services.dashboard.port') as number;  // 1111

if (isEnabled('home_assistant')) {
  const haPort = get('services.home_assistant.port');
  console.log(`HA available at http://localhost:${haPort}`);
}

Note

The dashboard serves the instance configuration (with secrets excluded) at the /api/config endpoint for client-side components.

Plist Templates

LaunchAgent plist files are generated from templates rather than hand-maintained. This ensures every plist stays in sync with instance.yaml and that secrets are injected at generation time from macOS Keychain.

If you’ve ever manually edited 11 plist files, changed a port number, missed one, and then spent 45 minutes watching logs from the wrong service — this system exists because of you. Well. Because of us.

Templates live in ~/.sanctum/templates/launchagents/ and use a {{PLACEHOLDER}} syntax:

<!-- Template: com.sanctum.gateway.plist -->
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN"
  "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
    <key>Label</key>
    <string>com.sanctum.gateway</string>
    <key>ProgramArguments</key>
    <array>
        <string>{{NODE_PATH}}</string>
        <string>{{GATEWAY_BIN}}</string>
        <string>gateway</string>
        <string>start</string>
        <string>--port</string>
        <string>{{GATEWAY_PORT}}</string>
    </array>
    <key>EnvironmentVariables</key>
    <dict>
        <key>GATEWAY_TOKEN</key>
        <string>{{GATEWAY_TOKEN}}</string>
    </dict>
    <key>RunAtLoad</key>
    <true/>
    <key>KeepAlive</key>
    <true/>
</dict>
</plist>

Generating Plists

The generate-plists.sh script renders all templates:

1. Reads instance.yaml for service ports, paths, and feature flags.
2. Pulls tokens from macOS Keychain (e.g., GATEWAY_TOKEN).
3. Skips templates for disabled services (enabled: false).
4. Writes rendered plists to ~/Library/LaunchAgents/.

# Preview what would be generated
~/.sanctum/generate-plists.sh --dry-run

# Generate and install all plists
~/.sanctum/generate-plists.sh

Caution

After regenerating plists, you must launchctl unload and launchctl load any changed agents for the new configuration to take effect. The watchdog will detect stopped services and restart them if needed. launchctl does not care about your feelings or your intention to restart things “in a minute.”

Secrets Management

Secrets never appear in instance.yaml or any configuration file. They are stored in two locations depending on the platform:

macOS (Keychain)

Tokens and API keys are stored in the macOS login Keychain. The plist generator and shell scripts retrieve them using the security command:

security find-generic-password -a "sanctum" -s "gateway-token" -w

Secrets are rotated monthly by the com.sanctum.rotate-secrets LaunchAgent, which runs on the 1st of each month at 3:30 AM. Nothing like waking up to fresh tokens you didn’t have to think about.

VM (SOPS + age)

On the VM, secrets are encrypted at rest using SOPS with age encryption:

# Encrypted file
~/.sanctum/secrets.enc.yaml

# Decrypted at gateway startup by the wrapper script
~/.sanctum/sops-start.sh

The sops-start.sh wrapper decrypts secrets into environment variables, starts the gateway, and never writes plaintext to disk. The secrets exist in memory only, like a thought you can’t quite remember but that still controls your house.

Danger

Never commit secrets to Git, never add them to instance.yaml, and never pass them as command-line arguments (they appear in ps output). Use Keychain on macOS and SOPS on the VM. If you’re reading this because you already did one of those things — rotate immediately. We’ll wait.

Adding a New Service

To add a new service to the configuration layer:

1. Add a services.<name> block to instance.yaml with at least enabled and port.
2. If the service needs a LaunchAgent, create a template in templates/launchagents/.
3. If the service needs secrets, store them in Keychain and reference them as {{PLACEHOLDER}} in the template.
4. Run generate-plists.sh to render the new plist.
5. Add the service to the appropriate node’s services list in instance.yaml.
6. Update the watchdog configuration if the service should be health-checked.

Note

Six steps. That’s not bad for a system that will now automatically start, monitor, restart, and health-check your new service across reboots and power failures. You’ve traded six steps for never thinking about it again. That’s the deal.
